8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min

Détails sur le produit:

Lieu d'origine: Dongguan Chine
Nom de marque: SENNY
Certification: CE SGS
Numéro de modèle: SRS826

Conditions de paiement et expédition:

Quantité de commande min: 1pc
Prix: negotiable
Détails d'emballage: Paquet de contreplaqué
Délai de livraison: 45 jours
Conditions de paiement: T / t
Capacité d'approvisionnement: 10 PC / mois
meilleur prix Contact

Détail Infomation

Numéro de modèle: SRS826 Couleur d'impression: 2 couleurs
Type de plaque: machine d'impression d'écran Garantie: 1 an
Services après-vente: Vidéo ou en ligne Détails d'emballage: Paquet de contreplaqué

Description de produit



8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min





Machine Feature



  • The machine is suitable for screen printing of various colors of UV ink,hot stamping,varnishing and other decorations on plastic soft tubes.

  • The machine adopts an integrated turntable design,all printing functions are completed in the same set of fixture,the printing accuracy is as high as ± 0.1 mm.

  • The machine is driven by digital control servo motor to realize 360-degree printing of products,equipped with remote management and service functions(industry 4.0).

  • The machine adopts well-known brand electrical components, PLC control system,easy-to-use touch screen and wireless tablet operation,with reliable performance.

8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min 0







Optional Configuration



  • Unscrambling & feeding machine.              Hot stamping function.                             Plasma surface treatment function.



  • Visual registration function.                         LED-UV Curing function.                         Finished product quality inspection function.





Technical Parameters



Machine Model SRS826
Work Station 8
Printing Speed Up to 80 pcs/min
Soft Tube Diameter 15-75mm
Soft Tube Height 60-220mm
Max.Printing Length 220mm
Max.Printing Height 180mm
Printing Accuracy ±0.1mm







Printing Sample







8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min 1

8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min 2







About us:



     In 2020, Shenli provided Russian customers with a CNC 1-color glazing + 3-color screen printing UV curing production line for hoses. Since then, Shenli has been capable of offering customers the production capacity of various CNC multi-color screen printing, gold stamping and quality inspection machines for hoses.



8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min 3



8 Station Soft Tube CNC 2-color Automatic UV Printing Machine 80 Pcs/Min 4
